60 Hp Rotary Screw Air Compressor
Our 60 HP rotary screw air compressor is a high-performance industrial air compression solution designed for continuous duty operation in demanding manufacturing environments. Powered by a 45kW permanent magnet synchronous motor (PMSM) with variable speed drive (VSD) technology, this oil-injected screw compressor delivers exceptional energy efficiency, low noise operation, and reliable compressed air supply for a wide range of industrial applications.
Whether you need compressed air for automotive manufacturing, food processing, textile production, or general factory operations, this 60 HP stationary screw air compressor provides the perfect balance of power, efficiency, and durability.
Key Features & Benefits
Energy Saving PM VSD Technology
Equipped with a permanent magnet synchronous motor and advanced variable frequency drive, this compressor adjusts motor speed according to real-time air demand. Compared to traditional fixed-speed compressors, energy savings of 30–40% can be achieved, significantly reducing electricity costs.
Direct Drive Air End
The direct drive design eliminates belt or gear transmission losses, ensuring higher transmission efficiency and lower maintenance requirements. The precision-engineered screw rotors deliver consistent airflow with minimal wear.
Low Noise Operation
Operating at approximately 70 dB(A), this low-noise rotary screw compressor creates a more comfortable working environment and complies with industrial noise regulations without requiring additional soundproofing.
Efficient Air Cooling System
The integrated air cooling system ensures optimal operating temperatures even in demanding conditions. Discharge temperature is maintained within ambient temperature +10–15°C, protecting downstream equipment and extending compressor life.
Reliable Protection Systems
Built-in protections include motor overload protection, phase sequence protection, high discharge temperature protection, and low oil pressure alarm - ensuring safe and reliable 24/7 operation.
Smart PLC Control
CThe intuitive PLC control panel provides real-time monitoring of operating parameters, fault alarms, and maintenance reminders. Users can easily set working pressure and monitor energy consumption.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Series | HM45-10 |
| Horsepower | 60 HP |
| Motor Power | 45 kW |
| Air Delivery @ 1.0 MPa | 6.5 m³/min |
| Working Pressure Range | 1.0MPa (10bar ) |
| Compressor Type | Twin-Screw / Single-Stage Compression |
| Drive Mode | Direct Drive (Coupling Connected) |
| Motor Type | Permanent Magnet Synchronous Motor (PMSM) |
| Speed Control | Variable Speed Drive (VSD) / Variable Frequency |
| Cooling Method | Air Cooling |
| Lubrication Style | Oil Injected / Oil Lubricated |
| Noise Level | ≤ 70 dB(A) |
| Application | Air Delivery in system |
| Type | Stationary |
| Power Supply | 380V / 50Hz / 3-Phase (Optional: 220V–480V, 50/60Hz) |
| Dimensions (L × W × H) | Approx. 1450 × 1000 × 1230 mm |
| Weight | Approx. 500 kg |
| Protection Level | IP54 / IP55 (Optional IP65) |
| Certification | CE, ISO 9001 |
| Warranty | 1 Years (24 Months) |
Why Choose Our 60 HP Screw Air Compressor?
Proven Air End Technology: Precision-machined screw rotors with asymmetric profile, backed by heavy-duty bearings for extended service life and minimal maintenance.
Up to 40% Energy Savings: The PM VSD system precisely matches air supply to demand, eliminating wasteful unload cycles and reducing peak current during startup.
Stable Pressure Output: Advanced PID control maintains discharge pressure within ±0.01 MPa, ensuring consistent air quality for sensitive pneumatic equipment.
Easy Maintenance: Spin-on oil filter and separator elements allow quick servicing. Large service doors provide easy access to all components.
Global Voltage Compatibility: Available in multiple voltage configurations (110V–480V, 50/60Hz) to suit different countries and regions.
Compact Footprint: Space-saving design integrates compressor, motor, cooler, and controls in one cabinet - ideal for workshops with limited floor space.
Environmentally Friendly: Low oil carryover (≤3 ppm) and energy-efficient operation reduce environmental impact and operating costs.
Applications
This 60 HP industrial rotary screw air compressor is widely used across multiple industries:
General Manufacturing: Assembly lines, pneumatic tools, machine shops, metal fabrication
Automotive Industry: Painting booths, tire inflation, power tools, robotic systems
Food & Beverage: Packaging machinery, bottling lines, product conveying (with proper filtration)
Textile Industry: Loom operation, yarn spinning, fabric processing
Electronics: PCB cleaning, component handling, precision assembly
Construction: Concrete spraying, rock drilling, pneumatic hammers
Pharmaceuticals: Process air for cleanroom applications (with appropriate downstream treatment)
Plastics & Rubber: Injection molding, extrusion, blow molding machines
Quality Assurance & Certifications
ISO 9001 Certified manufacturing processes ensuring consistent quality
CE Marking for European market compliance
100% Factory Tested before shipment - every unit runs for minimum 3 hours under load
Material Traceability for all pressure-bearing components
